	1、Servo Driven Independent servo driven system in each unit to guarantee stable register at high printing speed.
	2、Printing Unit Use the most advanced inking system which has 23 inking rolls, four large diameter form rolls included and alcohol damping system to guarantee printing quality.
	3、Pre-register system Based upon the printing length, input log data into the sliding console, each unit will automatically be adjusted to its ready position.
	4、Register System Each printing unit can remote adjust register which includes lineal, lateral and skewing without stopping the press to save time and reduce the waste of substrate.
	5、Vacuum Backflow Control Unwind Vacuum backflow cylinder can prevent scratches on the back of label paper during intermittent motion.
	6、No Joystick Fully automatic operation system including pressure adjustment, inking roll washup.roller clutch, etc.
	7、Easy to Operate Equipped with sliding touch screen console which can be moving around to increase the efficiency of operator.
	8、Printing Size Technology to minimize printing size to achieve larger scale of variable size printing.
	9、British Control System Apply electronic component from famous international brand to guarantee long term reliable operation.
	10、Lubrication System Centralized automatic lubrication.
	11、Adopt Latest German Technology of Offset Press Reasonable structure, low noise and energy consumption.

Technical Specification

Notes: With the viriation of the length to be printed, machine speed should be changed.

*lts overall dimension and manufacturing Process are subject to change without further notice.

Optionals

■ Automatic ink roller washup system
■ UV flexo printing station: Equipped with anilox roll to do the UV coating or white color printing on transparent material.
■ Remote inking system
■ Letterpress printing unit
■ Cold foil stamping device
■ Rotary diecutting device: Use flexible die and magnetic cylinder to do any shape's cutting.
■ Silk screen printing unit
■ Laminating device: A intermittent laminator can be added before rotary diecutting during high speed intermittent printing.
■ CCD Camera
■ Web guide system.
■ Digital printing unit:It is a colorful non-contact variable information printing system which can combine with traditional printing technology to perfect level.
